精确、效能、创新 nca-1611 nebs-compliant desktop vcpe appliance for sd-wan a
特点
- intel® xeon® d-1500 series 4~8 cores cpu (broadwell-de ns)
- 6x gbe rj45, 2x sfp (by sku), 2x sfp (by sku), 1 pair of gen3 bypass (by sku)
- 4x 288-pin long dimm, ddr4 2133mhz, 64gb (ecc) / 128gb (rdimm)
- intel® quickassist technology at 40gbps
- 1x rj45 console, 2x usb 3.0, optional 1x 2.5” hdd/ssd drive bay and 1 x satadom
- virtualization-ready design with sr-iov support
- 2x mini-pcie half size, one w/ sim holder (pcie/usb2.0)
- 90w 1 1 redundant psus
概述
the 8-core nca-1611 is a nebs-compliant desktop network appliance built with intel xeon d-1500 series cpu (codenamed broadwell-de ns). it is virtualization-ready, features 8x lan ports, 2x 10g sfp , up to 128gb system memory, and is optimized with sr-iov, allowing a device, such as a network adapter, to separate access to its resources among various pcie virtual functions.
in addition to being nebs-compliant, the nca-1611 is also k.21 certified. its carrier-grade design comes with intel® quickassist technology at 40g, ideal for sd-vpn and sd-security deployment scenarios. for wireless connectivity, the nca-1611 offers dual mini-pcie (one with sim reader), supporting wi-fi, lte, ipmi, simplifying service deployment at remote sites and most sme office branches.
外观
| cpu |
intel® xeon® d-1500 series 4~8 cores (broadwell-de ns) |
| chipset |
soc |
| bios |
ami spi flash bios |
| memory technology |
ddr4 2133mhz ecc/non-ecc/rdimm |
| memory capacity |
128gb |
| memory socket |
4 x 288-pin dimm |
|
| sata storage |
1 x 2.5” bay (optional) |
|
| default lan |
6 x gbe rj45 intel® i350-am4 |
| bypass |
1 pair gen3 (by sku) |
| digital i/o |
1 x gbe rj45 |
| usb 3.0 |
2 x type a |
| ipmi via opma slot |
ipmi onboard (by sku) |
| tpm |
yes |
| power input |
2 x dc jack |
| type/watt |
90w 1 1 redundant psus |
| expansion |
2 x mini-pcie half size, one w/ sim holder (pcie/usb2.0) |
| reset |
reset button * 1 |
| processor cooling |
passive cpu heatsink |
| system cooling |
3 x cooling fans |
|
| certifications |
rohs, ce/fcc, ul, cb |
|
| storage temperature |
-20°c to 70°c |
| operating temperature |
0°c to 50°c |
| operating humidity |
5% to 95% (non-condensing) |
| dimensions (w x h x d) |
275 mm x 44 mm x 310 mm (10.83" x 1.73" x 12.20") |
| weight |
3 kg (6.6 lbs) |
| watchdog |
yes |
| internal rtc |
yes |
| nca-1611a |
intel xeon d1543 8 cores, 6x gbe rj45 2x sfp 2x 10g sfp w/bmc |
| nca-1611b |
intel xeon d1543 8 cores, 6x gbe rj45 2x sfp 2x 10g sfp |
| nca-1611c |
intel xeon d1533 6 cores, 6x gbe rj45 2x sfp 2x 10g sfp w/bmc |
| nca-1611d |
intel xeon d1513 4 cores, 6x gbe rj45 2x sfp 2x 10g sfp |
| nca-1611e |
intel xeon d1513 4 cores, 6x gbe rj45 2x sfp
|
